2: Detection of UV lamp intensity:

1. Ultraviolet light is invisible light, purple light ≠ sterilization.

2. Ultraviolet rays are directed and refracted.

3. The penetration of ultraviolet light is weak.

4. The germicidal ultraviolet rays are in the C band, and the center wavelength is 2537AO

5. Ultraviolet bactericidal dose: intensity X time

6. The method of detecting the intensity of the ultraviolet lamp: ultraviolet intensity meter; ultraviolet intensity indicator card

7. The quality of the ultraviolet lamp: the glass has no bubbles and gas lines; fast start-up; no flicker; long life; irradiation intensity standard: 30W lamp new lamp ≥90µW/cm2; old lamp ≥70µW/cm2

8. Ultraviolet intensity test. Directly read the intensity value when irradiated at 100cm from the light vertically.

Note: ①Protection: Wear glasses, gloves, and a protective face shield if necessary.

②Read the test value after the UV lamp is stable for 5 minutes after turning on.

③The change of ultraviolet intensity is related to the quality and voltage of the lamp tube and the finish of the reflector.

3: The wattage is large, the power is large.

Serial numberproject typeparameter

1Input voltageAC 100-240V

2power8±1W

3Operating modeAlways on

4Power factor≥0.9

5Color temperatureUVC purple light + UVA indication

6Light-emitting surface1/2 luminous surface

7Beam angle120°

8Operating temperature-20℃to+45℃

9Storage temperature-30℃to+55℃

10Working humidity10%-80%

11delay0 seconds

12Product Size875*34*23mm

13Protection levelIP20

14Type and quantity of lamp beads10 UVC+UVA lamp beads eutectic

15product materialTransparent PC cover + aluminum AL6063
